Explore Swing Tag Design & Artwork
Online swing tag designer
Build a visual tag concept without specialist software. Add your logo, choose the format, shape, size, material, colours, finish and attachment, then export a preview or pass the specification into a quote.
Open the tag designerArtwork Setup
Prepare the production file: document dimensions, bleed, safe area, colour, images, fonts and supported export formats.
Design Decisions
Plan what the tag says, how the information is prioritised and how orientation, folds and the attachment affect the layout.
Technical & Templates
Use templates and specialist guidance for scannable codes, variable information and non-standard formats.
A practical artwork workflow
- Confirm the specification. Fix the finished size, shape, fold, hole position, material, print sides and any finish before building the final file.
- Build the layout. Establish information hierarchy, keep essential elements inside the safe area and allow the attachment to sit without obscuring content.
- Prepare production elements. Use the requested colour mode, suitable image resolution, embedded or outlined fonts and separate vectors for foil, Spot UV or cutting paths where required.
- Preflight and proof. Check dimensions, bleed, codes, spelling, variable data and overprint behaviour before approval.
If you have brand assets but cannot prepare print-ready files, review the artwork design service and provide a clear content brief.
Sizes that survive print on a small tag
A swing tag is read at arm's length and often at an angle, and much of its content is small. These are the limits worth designing to before the artwork is sent.
| Element | Keep it at least | Why |
|---|---|---|
| Body text | 6pt, or 7pt for reversed (white on colour) type | Below this, letters close up as ink spreads into the card |
| Thin lines and rules | 0.25pt | Finer lines break up or disappear |
| Type on kraft or coloured card | One size larger than on white | The card colour lowers contrast |
| QR codes | About 15mm square with a clear quiet margin | Smaller codes fail on older phone cameras |
| Barcodes | The size your retailer or scanner specifies | Scanners need full bar height and quiet zones |
| Foil, Spot UV and emboss detail | Bolder than printed detail | Fine strokes fill in on the plate |
| Bleed | 3mm past every trim edge | Covers the small movement of every cut |
What print and artwork choices cost
One, two or three colours cost the same as full colour; a matched Pantone spot colour adds an ink-matching setup. Printing the back scales every tag, and the artwork set-up service is a single charge. Prices are for 250 85 × 55mm tags printed full colour on one side (£68.00 as standard), all-inclusive with free UK delivery; each row changes only what it names.
| Option | 250 tags | Difference |
|---|---|---|
| One colour | £68.00 | No change |
| Pantone spot colour | £103.00 | +£35.00, including a £35.00 one-off setup |
| Front and back | £85.00 | +£17.00 |
| Artwork set-up help | £83.00 | +£15.00, including a £15.00 one-off setup |
Decision context
Build artwork from production constraints outward
Start with finished size, shape and information hierarchy, then add material, print and attachment constraints. This order protects readability and prevents an attractive layout from losing text to trim, folds, drill holes or special-finish tolerances. A supplied dieline should be the working boundary for every side.
Use CMYK or an agreed spot-colour method, suitable vector logos and images with enough effective resolution. Keep fonts embedded or provide outlined final text as requested. Barcodes and QR codes need a stable high-contrast area and must be tested at the actual printed dimensions.
Special processes need separate, named vector artwork. Foil, Spot UV, embossing, debossing, perforation and die-cut paths should not be represented only by a visual effect in the design file. Clear layers allow prepress to distinguish printed content from production instructions.
Follow the design guides in decision order: dimensions and folds, bleed and safe area, colour and file format, then logos, typography, codes and variable data. Finish with a full-size proof and a written specification so the visual file and intended product can be checked together.
