Shield Tag Shape & Artwork Guide
A shield swing tag (also known as a crest tag) features a heraldic silhouette with horizontal shoulders, tapered curved flanks, and a pointed base apex. Standard dimensions are 60×85mm and 70×100mm, die-cut to the outline for heritage fashion, equestrian brands and outerwear.
Shield & Crest Tag Design Geometry
Shield-shaped swing tags evoke traditional British craftsmanship, heritage tailoring, sports club crests, and premium outdoor apparel. The classical architectural proportions naturally frame heraldic logos, embossed seals, and royal warrants.
Technical Setup & Artwork Guidelines
- Standard Proportions: 60mm wide × 85mm tall (matches standard garment tag height while maintaining crest proportions).
- Top Drill Hole: The standard 3mm hole sits at the top centre, at least 5mm below the flat top edge, so the tag hangs upright without tilting.
- Bleed & Safe Margins: 3mm bleed outside the shield cut line; keep text and logos at least 4mm inside the curved edges.
Finishes for Heritage & Outerwear Branding
Shield tags pair exceptionally well with blind embossing or debossing to create a raised tactile crest. Adding a gold metal eyelet at the top suits the heritage look and reduces cord wear on heavy jackets and tweed garments; the hole is then 5mm rather than 3mm.
Order Finished Shield Tags
Configure your custom shield and crest swing tags with bespoke board stocks, eyelets, and luxury foil finishes.
Decision context
Protect legibility within the shield silhouette
A shield or crest shape carries a strong heritage, badge or sports association, but its tapered areas provide less print space than a rectangle of the same outer dimensions. Place the main identity in the broad central area and keep small product information away from the apex and shoulders.
Use a symmetrical vector path unless an intentional asymmetry is part of the approved design. Smooth transitions and adequate corner radii help the cut remain clean. Tight internal angles, thin borders and detail close to the edge can make normal production movement conspicuous.
The top attachment needs particular attention because the crest geometry may narrow near the hole. Allow enough board around the drill aperture and test eyelet size, cord movement and hanging balance. The tag should not tilt in a way that weakens the intended upright badge form.
Print a full-size paper cut-out and attach it to the product. Confirm dimensions, vector dieline, material, safe area, hole position and any foil or relief treatment. Strong visual symbolism works best when the underlying construction remains simple and readable.
